Two and three electrode systems can be used for the electrode systems can be used for the electrochemical sensors. Sensor technology may include fuel cell (O2) or amperometric (CO, H2S, ...) where the sample is oxidized or reduced. The electrochemical sensors for H2S and aCO are calibrated monthly with a ppm span gas and zero gas.

Model 10 Hydrogen Analyzer

Micro Electro Mechanical Systems, (MEMS technology) are defined as miniaturized mechanical and electro-mechanical devices that are manufactured using microfabrication. MEMS Technology enables a wide range of available flow sensors from 0-500 SCCM to 0-5 SLPM.

The micro flow sensor measures a change (cooling) in thermal conductivity between two sensors. Only one is in the gas stream which is cooled by flow of the medium. The differential output is proportional to the gas flow. The system has a high accuracy and good repeatability. The built-in temperature sensor compensates the flow for changes in temperature. The output is linear over the range of flow.

Model 20 MEMS Gas Flow Meters

The Model 30 is an analyzer for the measurement of toxic gases in the
workplace. This analyzer is unusual since it is easy to calibrate, has a fast response and has only one step to send logged (optional) data to a PC.

It uses electrochemical sensors for the measurement of ppb to ppm levels of selected toxins. It has many unique features.

We introduced the first commercial photoionization based instrumentation for industrial hygiene measurements of 1 ppm of vinyl chloride in 1974. Nearly 40,000 of the portable PIDs have been sold throughout the world for IH and safety measurement.

More than 50 United States Environmental Protection Agency and Occupational Safety & Health Administration (OSHA) methods based on PID have been published in the Federal Register.

Model 30 Electrochemical Sensor Analyzer

This analyzer has features and pricing like the early Model 102. The electronics have been upgraded, the lamp is the same long lifetime 10.6 eV but it does not have the capability to add 9.5 or 11.7 lamps. It does not have BT or WiFi. It does have a 2.4" OLED Display and LiPolymer battery. The Model 103 has many more features than this particul ar model.

Model 90 Basic Photoionization Analyzer

Model 95 - PID -Analyzer for Total VOCs & Hydrides in Air & Water

Model 95 Photoionization Analyzer

Model 103 - PID -Analyzer for Total VOCs & Hydrides in Air & Water

Model 103 Photoionization Analyzer

Photoionization (9.5, 10.0, 10.6, 11,7 eV ppm), Analyzer with ppb Mode+ 20 different EC, CG or IR sensors Up to 6 Channel Analyzers

Model 104 Photoionization Analyzer

The Model 112 is a low cost continuous VOC Analyzer. It has an optional 4-20 mA output, a single programmable setpoint, larger pump & an industrial NEMA 4 enclosure.

This 112 the choice of one 9.5 or 10.6 eV lamp, Operator's Manual, configuration software and RS232 cable.

Model 112 Fixed System PID

The Model 202 is a reliable & rugged dual beam non dispersive infrared (NDIR) monitor-ing system used primarily for the measurement of CO2, CH4, CO, & N2O hydrocarbons.

The PID Analyzers Infrared gas analyzer uses a dual beam interference filter instrument and has been designed with the process and plant environment in mind.

Model 202 Infrared Analyzer

PID Analyzers offers a new lightweight portable GC for IH, environmental, Process & Stack Monitoring, and Building Security applications.

The base Model 312 comes with Embedded Intel PC, Windows 10 OS, PeakWorks Software, Remote Control (worldwide for Troubleshooting, Training etc.)


Model 312 Portable GC

PID Analyzers offers a new lightweight transportable portable GC for environmental, quality control, natural gas... applications. The GC is extremely easy to use with its 10” VGA Color screen. It has significant data storage capability in a 32 GByte solid state drive, & a choice of one of our excellent GC detectors. The 323 will go anywhere with its light weight (17 #). The GC is powered by an Intel Pentium PC with Windows 10 operating system and PeakWorks chromatography software. This new gas chromatograph has a low mass column that allows fast GC programming.

Model 323 High Performance Fast GC


The Model 2012 is an analyzer for the measurement of accurate ppb levels of NOx, O3 & SO2 in ambient air & in the workplace. This analyzer is unusual since it is easy to calibrate, and operate. Well tested electrochemical sensors are provided for measuring common toxics in ambient air.
